Directory "ElectronicDocumentOutgoingEDOCAttachedFiles" (Accounting for Kazakhstan 3.0.74.2)

1. Identification

Purpose. The catalog is a file storage of the outgoing electronic document circulation subsystem of Kazakhstan. It stores metadata and content of files attached to the "Outgoing Electronic Document" documents. This includes files that the organization generates and sends to the counterparty via the "1C:EDO" service:

• XML of the outgoing electronic document;
• visualization of the document (PDF / print form);
• attached attachments;
• service files — containers for electronic signatures (.p7s) and service XML.

The catalog is auxiliary (service): the user works with files through the outgoing EDO document form and general file handling mechanisms of the BSP, while the catalog list is rarely opened directly.

Where to find: e1cib/list/Catalog.ElectronicDocumentOutgoingEDOCAttachedFiles

2. Header Attributes and Table Parts

2.1 Header Attributes (from evidence)

Standard attributes of the catalog: Code and Name (the name usually matches the file name), Owner — at the metadata level, DeletionMark.

2.2 Table Parts

For this type of service file storage catalog, custom table parts are generally absent. File versions and their binary content are stored not in a table part, but:

• in the value storage (attribute with binary data) — when stored "in the information base";
• or in the file storage volumes (FilePath + Volume) — when stored "in volumes on disk".

Requires verification in the specific build 3.0.74.2: presence of the binary data storage attribute and subordinate version catalog — the composition depends on whether file versioning is implemented for this catalog.

3. Forms

The user does not directly open these forms in the standard scenario — work is done through the "Outgoing Electronic Document" form and general file handling forms of the BSP ("Attached Files").

4. Key Module Procedures

No separate application BSL code in evidence for this catalog is provided. For the service catalog of attached files, a standard set of handlers applies (integration with the "File Handling" subsystem of the BSP):

Object Module:

• BeforeWriting(Refusal) — updating UniversalModificationDate, ModifiedBy, recalculation/check of HashSum and Size.
• OnCopying(CopyingObject) — resetting lock indicators (EditingUser, BorrowedDate) when copying an element.
• FillingProcessing(FillingData, ...) — setting Author, CreationDate from the current user and session.

Manager Module:

• Functions for obtaining/saving binary content of the file (working with value storage or volumes).
• FormRetrievalProcessing — substituting forms if necessary.

Element Form Module:

• OnOpening / OnCreatingOnServer — configuring field availability based on indicators Encrypted, SignedByES, ServiceFile, EditingUser.
• Commands "Open", "Save As", "Finish Editing", "Check Signature" — redirecting to general file handling and cryptography modules.

Requires verification: exact names of procedures and presence of overriding handlers are specific to build 3.0.74.2 (a review of the configurator/export is needed).

5. Posting and Movements

The object is a catalog, therefore it does not perform postings and movements in registers and does not generate accounting entries. It only stores files attached to the outgoing EDO document.

Accounting consequences arise from the source document to which the outgoing electronic document is attached (sales, payment, etc.). Typical entries of these documents according to the chart of accounts of the RK (Kazakhstan, 2026), for reference:

• Sale of goods (with outgoing ESF/SNT):
  • Dr 1210 "Short-term receivables from buyers" — Cr 6010 "Revenue from sales" — for the amount of revenue;
  • Dr 1210 — Cr 3130 "VAT payable" — VAT at the rate of 16% (RK rate 2026);
  • Dr 7010 "Cost of sales" — Cr 1330 "Goods" — write-off of cost.
• Receipt of money from the buyer: Dr 1030 "Money in current accounts" — Cr 1210.
• Settlements with the supplier (incoming direction, for comparison): Cr 3310 "Payables to suppliers".

Example of VAT calculation for the ESF line: with a product cost of 1,000,000 ₸, the VAT amount = 1,000,000 × 16% = 160,000 ₸, total payable 1,160,000 ₸.

The catalog itself interacts not with accounting registers, but with the file storage mechanism (value storage / file storage volumes) and with the registration journal during audit changes.

6. Related Objects and Input Based on

Owner / source of files:

• Document.ElectronicDocumentOutgoingEDOC — outgoing electronic document (attribute FileOwner).

Reference objects in attributes:

• Catalog.Users — Author, ModifiedBy, EditingUser;
• Catalog.FileStorageVolumes — Volume.

Adjacent subsystems:

• "1C:EDO" — generation and sending of XML of the outgoing document, receipt of receipts;
• IS ESF (electronic invoices) and SNT (accompanying invoices for goods) — sources of outgoing EDO RK;
• BSP subsystem "File Handling", "Electronic Signatures and Encryption".

Input based on: not applicable. The catalog is not a source/receiver for input based on; elements are created programmatically when attaching a file to the EDO document, not manually "based on".

7. Extension Points

• Event subscriptions BeforeWriting / OnWriting of the catalog — for additional validation of files (checking HashSum, limits Size, mandatory SignedByES for originals).
• Configuration extension: adding attributes (for example, file classification tag), overriding element/list forms, adding commands without removing from support.
• Overridable general BSP modules for file handling and cryptography — points for customizing scenarios for opening/saving/checking signatures.
• Roles and RLS: restricting access to files by Author and by document owner (organization, counterparty of the source document).
• Data exchange: UniversalModificationDate — a reference attribute for correct synchronization of files in RIB/exchanges.

General rule: it is preferable to extend behavior through event subscriptions and configuration extensions, without removing the standard object from support, to maintain release updatability.
