Catalog "File Versions" (Catalogs.FileVersions) — Technical Description

1. Identification

Object Characteristic. This is a service (technical) catalog of the file storage infrastructure. It is not an accounting object: it does not contain economic data, does not participate in accounting entries, is not tied to the chart of accounts, VAT, individual income tax, and other tax mechanisms of the RK. The catalog is maintained automatically by the file management subsystem and generally does not require direct user intervention.

Where to find: navigation link e1cib/list/Catalog.FileVersions. In the standard interface, access to versions is provided from the card of the attached file (button/command "Versions"), rather than through a separate menu item. Access control is inherited from the rights to the owner object of the file (document or catalog to which the file is attached).

2. Attributes and Table Parts

2.1 Header Attributes

Standard Attributes. In addition to those listed, the object has standard fields for the catalog: Code, Name (usually formed from the file name and version number), Owner (the owner of the version is an element of the catalog of attached files, for example Catalog.<Object>AttachedFiles), DeletionMark, Predefined, Reference.

2.2 Table Parts

The catalog does not have table parts. All information about the version is stored in the header attributes; the sequence of versions is built through the attribute ParentVersion and VersionNumber, not through table parts.

3. Forms

The catalog uses a set of BSP forms. Typically present are:

The main user interaction with versions occurs not through the catalog's own forms, but through the managed forms of the "File Management" subsystem: the card of the attached file and the "File Versions" form, which programmatically refer to this catalog.

4. Key Module Procedures

No custom code in evidence for this object is attached, so below are typical handlers and service procedures characteristic of this service catalog of BSP. Specific names of procedures and modules are clarified according to the version of BSP supplied with 3.0.74.2 (version-specific).

• FillProcessing / BeforeWriting (object module) — filling service fields: VersionNumber, CreationDate, Author, binding ParentVersion.
• Manager Module / common module FileManagement, FileManagementService — creating a new version (CreateVersion/AddFileVersion), obtaining the current and arbitrary version, rolling back to a version, deleting outdated versions.
• Text Extraction — procedures that fill TextStorage and TextExtractionStatus for full-text search (background task for text extraction).
• Storage Management — placing binary data in FileStorage (in the database) or on Volume with recording FilePath and FileStorageType; used when transferring files between volumes and the database.
• File Synchronization — comparison by UniversalModificationDate, binding Author to Catalog.FileSynchronizationAccounts.

5. Posting and Movements

The catalog is not posted and does not generate movements. It is a document-independent service catalog:

• there is no posting mode, no PostingProcessing handler;
• does not generate accounting entries and does not affect the chart of accounts of the RK (accounts 1210, 1030, 1330, 3310, 3130, 6010, 7010, etc. are not related to it);
• does not affect accumulation/information registers of the accounting contour;
• does not participate in the calculation of VAT (RK rate 2026 — 16%), individual income tax, pension contributions, social contributions, and social tax.

The only "movements" in a broad sense are changes to the file storage data themselves: writing binary data to FileStorage/on Volume and filling the registers of the full-text search subsystem during text extraction. They do not carry accounting significance.

Note. Attached files (including versions) are often attached to accounting documents — for example, to an invoice with VAT 16%, to an electronic invoice (ESF) (ESF information system) or to a tax return form. However, the catalog "FileVersions" only stores the content and history of the file, not the tax/sum data of the owner document.

6. Related Objects and Input on Basis

• File Owner — element of the catalog of attached files of a specific object (Catalog.<Object>AttachedFiles); through it, the version is linked to the document or element of the catalog.
• Catalog.FileStorageVolumes — attribute Volume (location of physical storage on disk).
• Catalog.Users / ExternalUsers / FileSynchronizationAccounts — attribute Author.
• Catalog.FileVersions (itself) — ParentVersion, chain of versions.
• Enumeration.FileStorageTypes, Enumeration.TextExtractionStatusFiles — service enumerations.

Input on Basis. The "Input on Basis" mechanism is not applied for this catalog. New versions are created automatically when the file is changed (uploading a new edition, editing through occupying/releasing the file), not by the command "Create on Basis".

7. Extension Points

• Configuration Extension — adding attributes (e.g., document classification labels) and form handlers without removing from support; permissible for service catalogs, but requires caution during BSP updates.
• BSP Programming Interfaces — working with versions through common modules of the "File Management" subsystem (creating, obtaining, rolling back versions) instead of direct object recording; preferred method of integration.
• Volumes and Storage Rules — configuring FileStorageVolumes and version storage policies (limiting quantity/storage duration) — standard way to manage volume without changing structure.
• Full-Text Search — influence on the composition of indexed content through TextStorage/TextExtractionStatus.

Requires verification (version-specific): exact names of module procedures and composition of service enumerations may differ depending on the version of BSP within the release 3.0.74.2.
