Directory "OrganizationsAttachedFiles" — Technical Description (Accounting for Kazakhstan 3.0.74.2)

1. Identification

Purpose. The catalog is intended for storing files attached to the elements of the “Organizations” catalog (both for the organization itself and for counterparties, if the storage model allows it). This is part of the standard universal subsystem for working with files in BSP (Library of Standard Subsystems). It stores documents, scans, images, and other materials related to a specific organization: copies of certificates, charter documents, scans of contracts, images of seals/logos, etc.

Files can be stored in two ways:

• in the information base — in a property of type ValueStorage;
• in file storage volumes — in external file storage on disk/network resource (then the FilePath property is filled).

Supported: file versioning, electronic signature (ES), encryption, text extraction for full-text search. Access to the file is strictly regulated by the rights to the owning organization: if the user does not have read access to the organization, they will not see the files attached to it.

2. Attributes and Table Parts

2.1 Header Attributes

Standard attributes of the file subsystem (present in objects of this type in BSP, complementing the list above):

The attribute Name (standard attribute of the catalog) stores the file name without the extension.

2.2 Table Parts

For the service catalog of attached files, there are generally no own table parts. Multiple data (versions, signatures, encryption certificates) are stored in separate subordinate catalogs/registers of the subsystem (for example, …FileVersions) and in storage attributes, not in the table parts of the main element.

3. Forms

The main working scenario is not the direct opening of catalog forms, but the embedded form of attached files in the organization card (standard form of the “File Management” subsystem in BSP), from which commands for adding, viewing, editing, signing, and encrypting are called.

4. Key Module Procedures

No separate BSL code for this object is attached in evidence. The logic is standard for attached files in BSP; it is mainly implemented in the common modules of the subsystem, not in the module of the catalog itself.

Object Module (BeforeWriting, OnCopying):

• filling Author, CreationDate upon creation; updating ModifiedBy, UniversalModificationDate upon writing;
• controlling file occupancy (EditingUser) before changing data.

Common modules of the file management subsystem (standard call points):

• FileManagement / FileManagementService — adding a file, reading/writing FileStorage, transferring between storages (IB ↔ volume);
• mechanism “Occupy/Release” — setting and removing editing lock through the EditingUser property;
• versioning — creating a new version when saving a modified file, maintaining history;
• ES and encryption — setting/checking signatures (SignedByES), encryption/decryption (Encrypted) using the “Electronic Signature” subsystem;
• text extraction — background filling of TextStorage for full-text search.

5. Posting and Movements

The catalog is not a document and does not perform posting — it does not generate movements in accounting/accumulation registers and accounting entries. This is a service data storage object.

Indirectly related to the recording of the element are:

• recording binary data in the FileStorage property (when stored in the IB) or placing the file in the volume with filling FilePath (when stored on disk);
• registration of the version in the file versioning mechanism;
• text indexing for full-text search.

For comparison: real postings in the configuration generate accounting documents (sales, receipts, etc.). For example, the sale of goods in the RK gives Dr 1210 Cr 6010 (income), Dr 7010 Cr 1330 (cost), Dr 1210 Cr 3130 (VAT at the rate of 16%, ed. 2026). The attached files catalog has no relation to this — it merely stores documents attached to the organization (for example, a scan of the VAT registration certificate).

6. Related Objects and Input Based On

Input based on is not applicable for the service catalog. The creation of an element is performed by the command to add a file from the organization card (drag and drop, selection from disk, from email/scanner).

7. Extension Points

• Configuration Extension — adding attributes (for example, category/type of document, validity period) and commands in forms without removing from support; overriding handlers BeforeWriting.
• Additional Attributes and Information — through the properties subsystem of BSP, files can be classified (document type, responsible) without changing metadata.
• Programming Interfaces of the “File Management” Subsystem — export methods of common modules for programmatically adding/reading files, working with versions, ES, and encryption.
• Storage Volume Configuration — moving files from IB to volumes to reduce database size; switching FileStorageType.
• Access Restriction (RLS) — access is inherited from the rights to the owning organization; if necessary, specified in access restriction templates.
• BSP Event Handlers (FileManagementOverridable and analogs) — points for embedding custom logic when working with attached files.

Requires verification (version-specific): the exact composition of the subsystem attributes (FileStorageType, StorageVolume, TextStorage) and names of common modules may differ in the specific build 3.0.74.2 — please check with the configurator.
