Directory "Enforcement Order Attached Files" — Technical Description

1. Identification

Purpose. The catalog stores files (scans, PDFs, images, documents) attached to the “Executive Sheet” documents. This is a service object of the “File Management” subsystem of the BSP: an instance of the catalog is created automatically when a file is attached to the executive sheet. The user interacts with it indirectly — through the panel/form of attached files of the owner document. The object provides storage of binary data (in the database or on disk volumes), versioning, encryption, electronic signing, and text extraction for full-text search. It is used by the accounting and HR departments when managing executive documents (collections for alimony, court decisions, etc.).

Each type of document that supports attached files has its own catalog of the form <DocumentName>AttachedFiles. This catalog is a container for files specifically for the “Executive Sheet” document.

2. Attributes

2.1 Header Attributes

Additionally (standard catalog attributes): Name — file name without extension; Code — service code; DeletionMark, Predefined (not used).

2.2 Table Parts

This catalog does not have table parts. All file attributes are stored in the header attributes; versions, signatures, and the binary data itself are placed in service information registers of the file management subsystem (see section 5).

3. Forms

Separate custom forms for the attached files catalog are generally not created — work is conducted through common forms and mechanisms of the BSP. The following are practically used:

If the configuration does not specify custom forms for the object, the platform generates them automatically; functionality is fully provided by the common BSP forms “File Management”.

4. Key Module Procedures

The application code in the catalog module is usually minimal; all logic is concentrated in the common modules of the “File Management” subsystem of the BSP. Typical handlers and logic points for this type of object:

• ManagerModule / ObjectModule — handler BeforeWriting: control of mandatory attributes filling (Author, CreationDate, FileStorageType), updating UniversalModificationDate and ModifiedBy.
• FileManagement (common module) — AddFile, UpdateFileVersion, OccupyFile / CancelFileEditing, ReleaseFile: creating a catalog record, placing binary data in the database or volume, maintaining versions.
• FileManagementService / …ClientServer — determining Extension, Size, ImageIndex from the uploaded file; selecting volume via FileStorageVolumes.
• ElectronicSignature — signing/verifying EP, setting the flag SignedEP.
• Encryption — encrypting/decrypting data, setting the flag Encrypted.
• FileTextExtraction (scheduled task) — extracting text into TextStorage, setting TextExtractionStatus.

Specific paths path:string in the provided evidence are absent, therefore typical handlers of this type of object are listed. The composition of called procedures is version-specific and is clarified by the modules of the specific assembly 3.0.74.2.

5. Posting and Movements

The catalog is not a document and is not posted — it does not generate entries in the chart of accounts and movements in accumulation/accounting registers. Economic operations and amounts (collections, withholdings, VAT, etc.) are reflected by the owner document “Executive Sheet” and related calculation documents, not the file storage.

Data of the object participate in service registers of the “File Management” subsystem:

For reference — numerical specifics of RK-2026, applied in owner documents (not in this catalog): VAT rate 16%; MRP = 4,325 ₸, MZP = 85,000 ₸; PIT 10% (15% over 8,500 MRP annual income); standard deduction for PIT — 30 MRP/month, but not more than 360 MRP/year; OPE 10% (base ceiling 50 MZP), OPEP 3.5%, VOSMS 2%, OSMS 3%, SO 5%, social tax 6%. Typical accounts of the RK: 1210, 1030, 1330, 3310, 3130, 6010, 7010. Electronic documents — ESF (IS ESF) and SCT. Currency — tenge (₸). These values relate to accounting documents of the configuration; the attached file storage does not use them.

6. Related Objects and Input Based On

• Document “ExecutiveSheet” — owner of the files (attribute FileOwner). Catalog records are created from the form of this document.
• Catalog “Users” — attributes Author, ModifiedBy, EditingUser.
• Catalog “FileStorageVolumes” — attribute Volume when stored on disk.
• Enumerations FileStorageTypes, TextExtractionStatuses.
• BSP subsystem “File Management” — registers of versions, EP, encryption, texts.

Input based on for this object is not provided: records are generated only by the file attachment mechanism, not by the “Create Based On” commands.

7. Extension Points

• Event subscriptions BeforeWriting / OnWriting of the catalog — additional control (for example, limiting extensions or maximum file size for executive sheets).
• Overridable BSP modules FileManagementOverridable, ElectronicSignatureOverridable — setting rules for storage, signing, encryption.
• Configuration extension — adding custom attributes (category/type of executive document) and borrowing forms of attached files.
• Rights and RLS — restricting access to executive sheet files at the level of roles and access group profiles.
• Scheduled task for text extraction — extending scenarios for full-text search in attachments.

Where to Find

Navigation link 1C: e1cib/list/Catalog.ExecutiveSheetAttachedFiles

Through the interface, the object is opened indirectly — from the document “Executive Sheet” via the command to work with attached files.
